Episode 3: Pestbusters II

Friday, September 26, 2008 – Three weeks of analysis, design, and testing later, Supervisor and The Reader meet in the Lounge.


Adding Collaborating Actors to a Use Case Diagram

Here we see our ideas from Episode 2 expanded and elaborated. Again, Use Case Diagrams are about requirements in context. Actors are persons or things that are outside your system but that interact with your system. By adding Collaborating Actors, you can show participants in the goals of an initiating Actor.
Who or what has to provide information as your system works through the Use Case? Who or what must be notified of the results?

And I emphasize or what. In our examples so far, the Actors have all been people (or Pest, who counts as a person for this example). But another computer system or device that participates in a Use Case also counts as an Actor from a requirements perspective. When we look at deployment, we’ll model these as systems or devices (there’s a surprise…); but from a requirements point of view, you probably do the same work when a person files a damage claim as when an automated system files the damage claim.

UML stereotypes and custom icons

Once I’ve explained this, you can easily grasp the concepts that Actor means outside person or thing and stick figure means Actor. So if you were working on my current client’s project (diagnostic systems for Harley-Davidson motorcycles[1]), you would be comfortable with this image:





But Use Case Diagrams aren’t just for you! As I discuss below, your customers should review these to help you validate them. And I guarantee that when my end customers see this picture, they’re gonna ask, “Who’s this person called Motorcycle? Is that the rider, or the owner, or the technician, or…?” UML is all about communication, and I just failed to communicate.

There’s an answer for this, and it’s found in UML stereotypes. A stereotype is a custom extension to the UML notation. From a UML perspective, a stick figure called Motorcycle is perfectly sensible. UML has no need for a special notation just for motorcycles. But my project does. So in my Motorcycle Diagnostics model, I added a stereotype: <<motorcycle>>. UML uses <<double angle brackets>> to indicate stereotypes. When you define a stereotype, you’re defining your own local “dialect” of UML.

Now that I’ve explained that notation, it’s easy for you to pick out the motorcycles in this picture:





But when the customers look at this diagram, once again they’re gonna ask, “Who are these people? The riders?”
For as long as people have been drawing pictures, “stick figure” has meant “person”. Don’t expect that to change just because you’re now speaking UML.

But never fear! UML can be further extended by defining a custom icon for a given stereotype. When you have nonhuman Actors, you can increase the readability of your diagrams a lot by creating custom icons. For instance, there’s no confusion when my customers look at this diagram:




That is communication. Bad art, but communication.

In fact, this comic strip is full of stereotypes from start to finish. Every character in this strip should be a simple stick figure, like Technician in the diagram above. But that wouldn’t be nearly as much fun.

Who is the audience for UML diagrams?

I’m often asked that question: “Who should read these diagrams? Who are we drawing them for?”

And the response I often hear, even before I can answer, is “Ewww, these are complicated. Let’s just keep these to the development team.
And whatever you do, don’t show them to the customers! That will scare them away!”

The question and the response are natural if you think of UML in the wrong way, the way I think is all too common: as a technology discipline.
It’s not. I’m gonna say this again (and again, and again, and…): It’s all about communication.
So the answer to “Who should read these diagrams?” is “Who are you communicating with?”

Now specific diagrams may be better suited to some audiences than to others. In my first speech class, Mrs. Roberts taught us the importance of MAP:

  • Medium: What medium are you using to convey your message? (Medium can also include setting.)
  • Audience: Who are you trying to convey it to?
  • Purpose: Why are you conveying it?

Your Purpose will vary at different points in your process. Sometimes you’re trying to understand user needs, and sometimes you’re trying to work out complex implementation issues. And different messages are aimed at different Audiences. If you’re discussing requirements, your Audience includes
customers and end users. For that audience, Use Case Diagrams are entirely appropriate if you draw them in the customer’s language.

In later Episodes, we’ll see Activity Diagrams. Again, those are very appropriate for customers, because they’re just pictures of the customer’s business rules. We’ll add Swimlanes to these, representing parts of the system. Those may be appropriate for customers, depending on whether they’re
“visible” parts or “internal” parts. We’ll see Class Diagrams, which can be appropriate for customers, depending on the level of detail.

Who is the Audience for UML diagrams? The best answer I can give is the Universal Answer: “It depends…”

[1] As described at http://www.spx.com/Archive/pdf/ideas_in_action/Harley%20Davidson_08.pdf.

Episode 2: Who Ya Gonna Call?

Thursday, September 25, 2008 – The UML Guy really gets into Use Case Diagrams!






Some useful Use Case Diagrams

In this diagram, we see some truly useful Use Case Diagrams. These diagrams are about requirements in context. Too often, we receive requirements as just a bulleted list of features, or a bulleted “The system shall…” list: “The system shall allow users to file receipts. The system shall reconcile receipts against outstanding invoices. The system shall become so convoluted and ill-defined that there’s no chance you’ll ever implement it correctly.”

These bullet lists aren’t bad (well, some are…), but they’re incomplete. They don’t tell you who requires specific features, nor what goals they want to accomplish through those features. As a description of requirements, they’re a starting point at best. Too often, they’re a trap: seemingly complete, but not.

Use Case analysis is all about putting requirements into a context. Who needs this feature? Why do they need it? How will they use it? What will they produce with it? How will they know it’s correct? How often will they use it? What steps will they follow? What rules and constraints apply? Who else will be involved?

There are a lot of techniques in good Use Case analysis, much more than can be captured in a simple diagram (or in a comic strip). Cockburn has a lot to teach on that subject. [1] But good Use Case Diagrams are a starting point. And busy teams may find they can’t squeeze in time for the Full Cockburn on every Use Case, but can use the diagrams to discuss which Use Cases require more detailed analysis. Agile teams in particular may prefer this approach, because Agile Development emphasizes the minimum documentation needed to successfully meet the requirements. Obsessively following the Full Cockburn (perhaps due to management dictate) can end up with 15 pages of documentation for Log In, without any actual code. It’s more Agile to start with Use Case Diagrams, and then add more detail where you find it’s necessary. Don’t underanalyze, but definitely don’t overanalyze.

I should add: there’s no UML reason I couldn’t have put all these Use Cases and Actors into one big diagram. I see it done all the time. And most of the time, it’s a mistake (in my opinion). The diagram gets too big, with too much going on. Individual details get lost in the confusion. Even though you drew it as one diagram, readers end up reading it as smaller diagrams within the diagram, focusing just on one Actor and that Actor’s Use Cases at a time. So it’s better to draw it as separate diagrams in the first place. (You’re not gonna listen to me. I know that. But I’m telling you what my experience has been.)

[1] Alistair Cockburn, Writing Effective Use Cases (ISBN 0201702258).




Episode 1: Friday Night in Ulterior Motive Lounge

Wednesday, September 24, 2008 – The Reader, a harried project lead, wishes he could get his development under control.

A first Use Case Diagram

This Episode introduces the absolute minimum useful Use Case Diagram. If it seems simple, it is. I want to show you that “speaking” UML is easy, if you start simple and grow. I don’t want to overpromise. UML isn’t a cure-all. It’s just a tool for communication. Let me repeat: It’s all about communication.

And if this diagram seems trivial, well, keep reading! We’ll get more complex.

And if you don’t understand the porkpie hat and Swingin’ on a Star, you should go rent Bruce Willis’s masterpiece, Hudson Hawk. You’ll love me for it, or you’ll hate me; but you won’t easily forget it.

UML in One Minute

UML is all about communication. It’s a diagram-based Language.

UML is not a process. It can be used in any process, from ad hoc to Agile to Orchestrated Development.

UML is not a tool. You don’t need Microsoft Word to speak, read, and write English. You don’t need any tool to “speak” UML. (But a good tool can make it easier!)

UML is not like the Oxford English Dictionary. It’s not formal, unless you need to be formal.

UML is a diagram-based language for building Models.




UML is not about code. It’s not even about software design. It’s about models of systems, where…

  • System = Structure + Behavior + Purpose.
  • Structure is expressed in Class Diagrams, Component Diagrams, Deployment Diagrams, and more.
  • Behavior is expressed in Activity Diagrams, State Diagrams, Sequence Diagrams, Communication Diagrams, and more.
  • Purpose is expressed in Use Case Diagrams, Activity Diagrams, State Diagrams, and more.

UML is a diagram-based language for building models using a Unified notation.

UML incorporates best of breed from prior notations.

Elements in one diagram can appear in other diagrams and add more detail.

One kind of diagram can add detail to another kind of diagram if you choose to use it that way.

These messages bear repeating. Expect me to repeat them.
